Indo Farm 3090 DI Specifications
Indo Farm 3090 DI
2WD 18.00 Lakh - 18.20 LakhSpecifications
| Indo Farm 3090 DI Engine | |
|---|---|
| Engine rated RPM | 2200 RPM |
| HP Category | 90 HP |
| Displacement CC in | 4088 CC |
| No. of cylinder | 4 Cylinder |
| Max Torque - Nm | 354 Nm |
| Air Cleaner / Filter | dry-type |
| Cooling System | water-cooled |
| Emission standard | Bharat Stage IV (BS‑4) |
| Fuel type | diesel |
| Fuel Pump Type | inline |
| Power KW | 67.14 KW |
| stroke in (mm) | 105 mm |
| Bore in (mm) | 118 mm |
| Fuel Pump Capacity | inline Lit |
| Dry Weight kg | 2530 Kg |
| Height | 1740 mm |
| Starter Motor | self-starter |
| Accessories | Tailor Hook ,Fender Guard ,Heavy Bumper ,Tool Kit ,Operator Manual , Top Link |
| Shifting Type | side shift gear lever |
| Hydraulics | gear-type |
| Cylinder Capacity cc | 4088 CC |
| Indo Farm 3090 DI Transmission | |
| Transmission type | constant mesh |
| No. of gears Forward | 8 Forward |
| No. of gears Reverse | 2 Reverse |
| Speed Forward - kmph | 2.92 – 35.76 Kmph |
| Speed Reverse - kmph | 3.88 – 15.55 Kmph |
| Brakes type | oil-immersed multiple disc |
| clutch type | dual |
| Gear Box Type | 8 forward + 2 reverse |
| Front Axle | NA |
| Rear Axle | NA |
| Linkage Category | Category-II |
| Indo Farm 3090 DI Power Take Off | |
| Max PTO (HP) | 76.5 HP |
| PTO RPM @ engine, rpm | 540 RPM |
| PTO Type | 6-spline |
| PTO Speed | 540 |
| Indo Farm 3090 DI Steering | |
| Steering Column | hydrostatic |
| Steering type | Hydrostatic Power |
| Indo Farm 3090 DI Hydraulic | |
| Lifting Capacity Max. | 2400 Kg |
| 3 Point Linkage | Category II |
| Spool Valve | selective control valve (SCV) |
| Type | 2WD |
| Pump Type | gear-type |
| Lower Link | three-point |
| Indo Farm 3090 DI Dimensions & Weight | |
| Ground Clearance | 400 Nm |
| Total Weight | 2530 Kg |
| Turning radius With Brake | 4.5 Nm |
| Turning radius Without Brake | 3970 mm |
| Overall Length | 3990 mm |
| Overall Width | 1980 mm |
| Wheel Base | 2130 mm |
| Height | 1740 |
| Indo Farm 3090 DI Wheels & Tyres | |
| Tyre Size Front | 7.50 x 16 |
| Tyre Size Rear | 16.9 x 30 |
| Type Front | NA |
| Type Rear | NA |
| Type | 2WD |
| Wheel Track Front | 7.5 × 16 |
| Wheel Track Rear | 16.9 × 30 |
| Indo Farm 3090 DI Electrical | |
| Battery Capacity | 12V, 88 Ah AH |
| Alternator | 12V |
| Battery Type | 12-volt, 88 Ah |
| Horn | NA |
| Indicator & Gauge | NA |
| Electrical System | NA |
| Electrical Overview | NA |
| Indo Farm 3090 DI Others | |
| Blow Rating | NA |
| Tractor Detail | NA |
| Accessories | NA |
| Special Application | NA |
Please read Safety Tips carefully before making any purchase
Know More
Indo Farm 3090 DI Tractor
The agricultural sector plays a vital role in the Indian Economy. But, nowadays agricultural farming depends on advanced machinery, tools, and equipment. You will get Indo Farm 3090 DI tractor specifications here. Every new day, new brand tractors are coming up with advanced features and technology and are boosting the Indian market as well as satisfying the needs of the farmers. Indo Farm 3090 DI tractor is manufactured by one of the most popular brands In India, 22- 23 tractor brands are manufactured across the country with excellent specifications and automotive productions.
If we talk about the tractors, so every tractor has its own specialty in the form of features and the benefits provided in them. Indo Farm is one of the trusted brands in India. These features help the customers to research and compare with the other tractor models. Indo Farm 3090 DI has 90 HP. Some of the specific features that buyer's focussed before purchasing the tractor are utility, budget, comfort and safety, comparison, and consultation with the dealers.
Additionally, the specifications are listed as more 'engine power' and more tractor runs. You will get 81-90 HP Range in Indo Farm 3090 DI. The other factor goes with the transmission which includes gears, reverse, and forward speed, the functioning of brakes, and power of the single and dual-clutch system. Indo Farm 3090 DI tractor has 2WD. The hydraulics make the turning easier which is also used for lifting attachments and implements. The PTO shaft is the part of the equipment located in the tractor.
Indo Farm 3090 DI tractor has 4088 CC displacement in CC. The tires and battery capacity tell the smooth functioning of the tractor. Tractor Indo Farm 3090 DI has 4 number of cylinders. You will get 8 forward + 2 reverse PTO HP in the tractor Indo Farm 3090 DI.
This tractor provides a 76.5 gearbox.
So, if you are looking for the tractor price of the tractor go through the official links, websites, and dealers and services like Khetigaadi that provide reliable information to the customers.
