Massey Ferguson 5245 DI Planetary plus V1 2WD

Change Tractor
2WD
HP Category : 50 HP
Displacement CC in : 2700 CC
No. of cylinder : 3 Cylinder
Max PTO (HP) : 42.5 HP HP
Gear Box Type : 8 Forward + 2 Reverse

Massey Ferguson 5245 DI Planetary plus V1 2WD Tractor has the comfort and convenience features to keep you smiling even during the longest days

  • 50 HP
  • 2WD
  • 2700 CC
  • 3 Cylinder
  • 42.5 HP HP
  • 8 Forward + 2 Reverse

Massey Ferguson 5245 DI Planetary Plus V1 2WD :


The Massey Ferguson 5245 DI Planetary Plus V1 tractor is manufactured by India’s leading tractor manufacturing company, TAFE. Massey Ferguson tractors have a very classic and attractive design. Here we are giving you all the important information about 5245 DI Planetary Plus V1 2WD. To know about the Tractor Price contact Khetigaadi executives.


Massey Ferguson 5245 DI Planetary Plus V1 2WD Engine Capacity:


The Massey Ferguson 5245 DI Planetary Plus V1 2WD tractor’s HP is 50 HP. The Massey Ferguson 5245 DI Planetary Plus V1 2WD tractor’s engine capacity is 2270 cc and has 3 cylinders generating 2700 engine rated RPM.


Why should you choose the Massey Ferguson 5245 DI Planetary Plus V1 2WD tractor model?


Massey Ferguson 5245 DI Planetary Plus V1 2WD tractor has a dual dry type clutch, which provides smooth and easy functioning. Massey Ferguson 5245 DI Planetary Plus V1 2WD trator’s steering type is manual steering; ;from that, the tractor gets easy to control and fast response. The Massey Ferguson 5245 DI Planetary Plus V1 2WD tractor has oil-immersed brakes, which provide high grip and low slippage.The Massey Ferguson 5245 DI Planetary Plus V1 2WD tractor has a hydraulic lifting capacity of 1700 kg and Massey Ferguson 5245 DI Planetary Plus V1 2WD tractors mileage is economical in every field.


Massey Ferguson 5245 DI Planetary Plus V1 2WD Specifications:


No. Of Cylinder

3

HP Category

50 HP

Capacity CC

2700 CC

Engine Rated RPM

2700 RPM

Cooling

WATER COOLED

Air Filter

Oil Bath With Pre Cleaner

PTO HP

42.5

Transmission Type

Partial constant mesh

Clutch

DRY TYPE DUAL

Gear Box

8 Forward + 2 Reverse

Battery

12 V 75 AH

Alternator

12 V 36 A

Forward Speed

34.8 kmph

Brakes

OIL IMMERSED Brakes

Steering Type

Mechanical/SINGLE DROP ARM

PTO Type

LIVE 6 SPLINE PTO

RPM

540@ 1790 ERPM

Fuel Tank Capacity

47 liter

Total Weight

2100 KG

Wheel Base

1785 MM

Overall Length

3380 MM

Overall Width

1715 MM

Ground Clearance

340 MM

Turning Radius With Brakes

2850 MM

Lifting Capacity

1700 Kgf

3 point Linkage

DRAFT , POSITION AND RESPONSE CONTROL LINKS

Wheel drive

2 WD

Front Wheel

6.00 X 16

Rear Wheel

14.9 X 28

Status

Launched


Massey Ferguson 5245 Planetary Plus Tractor Specification in Details


Engine and Performance:

  • There are 50 horsepower in the Massey Ferguson 5245 DI Planetary Plus HP. Its durability allows it to manage challenging tasks like driving large tractor tools and navigating difficult terrain with ease.

  • This tractor is equipped with a SIMPSONS SJ327 TIII A diesel engine. Its engine has 3 cylinders and a displacement of 2700 cc. Increased engine capacity results in increased power output for a variety of difficult tasks.

  • There is an inline fuel pump included with this tractor. The engine will receive fuel from this fuel pump in an appropriate manner.


Transmission:

  • There is a partially constant mesh gearbox in the gearbox system. To enable more comfortable and smooth gear shifts, this gearbox has some of its gears active all the time.

  • There is a dual-clutch system included. This clutch ensures faster gear-shifting operations by combining two clutch plates into a single gear lever, allowing the PTO and gearbox to be operated separately.

  • A gear system with 8 forward and 2 reverse or 10 forward and 2 reverse gears is an additional aspect of it. This tractor has more gear ratios that provide the right speeds for

a variety of terrain and large loads. 4.8 km/h is the tractor's top forward speed.


Hydraulic:

  • A lifting capacity of 1700 kg is provided by the Massey Ferguson 5245 DI Planetary Plus. It can therefore move large objects and operate heavy-duty equipment like disc hoops and balers.

  • There is a three-point connection available for both Categories I and II. The hydraulic control includes position, draft, and reaction control. The system modifies the depth of the implements in response to unstable ground conditions.


Brake & Steering :

  • There is also a multi-disc braking system immersed in oil. The enhanced heat-dissipating features of the braking system minimise brake fade.

  • Power and mechanical steering are available options. Power steering greatly simplifies the process of handling a heavy vehicle and makes turning on uneven surfaces simpler.




Similar New Tractor

Similar Compare Tractors

Disclaimer

This product information is generic in nature and based on information provided by company or on its website. Please contact company or dealer for up-to-date information. Please report any error at connect@khetigaadi.com.

FAQS - ABOUT Massey Ferguson 5245 DI Planetary plus V1 2WD Tractor

Ans : A tractor with 50 HP is the Massey Ferguson 5245 Planetary Plus V1.

Ans : The lifting capacity of the Massey Ferguson 5245 Planetary Plus V1 is 1700 kg.

Ans : Mechnical Steering is available on the Massey Ferguson 5245 Planetary Plus V1 tractor.

Ans : Find Massey Ferguson 5245 Planetary Plus V1 dealer nearby on Khetigaadi.

Ans : The brakes of the Massey Ferguson 5245 Planetary Plus V1 tractor are Multi Disk Oil Immersed Brakes.

Ans : 8F + 2R gears are included in the Massey Ferguson 5245 Planetary Plus V1 Tractor.

Ans : The fuel tank capacity of the Massey Ferguson 5245 Planetary Plus V1 Tractor is 47 litres.
