| Engine Type : | John Deere 5029D, 41 HP, 2100 RPM, 3 Cylinders, Coolant cooled with overflow Reservoir, Naturally aspirated |
|---|---|
| Engine Rated RPM : | 2100 |
| Engine HP : | 41 |
| No. of Cylinder : | 3 |
| Air Cleaner / Filter : | Dry Air Cleaner |
| Transmission Type : | Collarshift |
|---|---|
| Max Speed : | 3.25 - 35.51 |
| Speed Reverse - kmph : | 4.27- 15.45 |
| Power Take Off (P.T.O rpm) : | 540 @ 1600 ERPM, 540 @ 2100 ERPM |
| No. of gears Forward : | 8 |
| No. of gears Reverse : | 4 |
| Brakes Type : | Oil Immersed Disc Brakes |
| Clutch Type : | Single / Dual |
| P.T.O. Type : | Independent, 6 Splines |
|---|---|
| PTO RPM : | 540 @ 1600 ERPM, 540 @ 2100 ERPM |
| Steering Type : | Power |
|---|
| Lifting Capacity at Standard Frame : | 1600 Kgf |
|---|---|
| 3 Point Linkage : | CAT ll, Automatic depth and draft control |
| Total Weight : | 1760 Kg |
|---|---|
| Wheel Base : | 1970 mm |
| Overall Length : | 3400 mm |
| Overall Width : | 1780 mm |
| Ground Clearance : | 0390 mm |
| Turning Radius of Brakes : | 2900 |
| Drive : | 2WD |
|---|---|
| Front Tyre : | 6.0 X 16 (0.15 x 0.41 m) 8 PR |
| Rear Tyre : | 12.4 x 28 (0.31 x 0.71 m), 12 PR (Optional) 13.6 x 28 (0.34 x 0.71 m), 12 PR |
| Battery Capacity : | 12 V 88 AH |
|---|---|
| Starter Motor : | 2.5 kW |
| Alternator : | 12 V 40 A |
| Optional Accessories : | Ballast Weight, Canopy, Canopy Holder, Drawbar, Wagon Hitch, Tow Hook |
|---|
