Swaraj 843 XM Specifications
Specifications
Engine
| Engine type | 4 Stroke, Direct Injection, Diesel Engine |
|---|---|
| Engine rated RPM | 1900 RPM |
| Engine HP | 42 HP |
| Displacement CC in | 2730 CC |
| No. of cylinder | 4 Cylinder |
| Air Cleaner / Filter | 3- Stage Oil Bath Type |
| Cooling System | Water Cooled with No loss tank |
| Fuel type | Diesel |
| stroke in (mm) | 110 mm |
| Bore in (mm) | 88.9 mm |
| Fuel Tank Capacity | 47 ltrs |
| Height | 2270 mm |
Transmission
| No. of gears Forward | 8 |
|---|---|
| No. of gears Reverse | 2 |
| Speed Forward - kmph | 2.3 - 29.3 kmph |
| Speed Reverse - kmph | 2.7 - 10.6 kmph |
| Brakes type | Oil Immersed Brakes |
| Gear Box Type | 8 Forward + 2 Reverse Fully Constant |
Power Take Off
| Max PTO (HP) | 38.4 PTO HP |
|---|---|
| PTO RPM @ engine, rpm | 540 RPM |
Steering
| Steering type | Mechanical Steering |
|---|
Hydraulic
| Lifting Capacity Max. | 1000 kg |
|---|---|
| 3 Point Linkage | 3 point linkage Category-I suitable for Category-II type implement pins |
| Type | Live With Position control, Automatic draft control and Mix Control |
Dimensions & Weight
| Ground Clearance | 293 mm |
|---|---|
| Total Weight | 1830 kg |
| Overall Length | 3460 mm |
| Overall Width | 1740 mm |
| Wheel Base | 2055 mm |
Wheels & Tyres
| Tyre Size Front | 6.00 x 16 mm |
|---|---|
| Tyre Size Rear | 12.4 x 28 mm |
| Type Front | 1320 |
| Type Rear | 1350 (with 12.4*28 tyre type) |
Electrical
| Battery Capacity | 12 V, 88 Ah |
|---|---|
Know More
Swaraj 843 XM Tractor
The agricultural sector plays a vital role in the Indian Economy. But, nowadays agricultural farming depends on advanced machinery, tools, and equipment. You will get Swaraj 843 XM tractor specifications here. Every new day, new brand tractors are coming up with advanced features and technology and are boosting the Indian market as well as satisfying the needs of the farmers. Swaraj 843 XM tractor is manufactured by one of the most popular brands In India, 22- 23 tractor brands are manufactured across the country with excellent specifications and automotive productions.
If we talk about the tractors, so every tractor has its own specialty in the form of features and the benefits provided in them. Swaraj is one of the trusted brands in India. These features help the customers to research and compare with the other tractor models. Swaraj 843 XM has 42 HP. Some of the specific features that buyer's focussed before purchasing the tractor are utility, budget, comfort and safety, comparison, and consultation with the dealers.
Additionally, the specifications are listed as more 'engine power' and more tractor runs. You will get 41-50 HP Range in Swaraj 843 XM. The other factor goes with the transmission which includes gears, reverse, and forward speed, the functioning of brakes, and power of the single and dual-clutch system. Swaraj 843 XM tractor has 2WD. The hydraulics make the turning easier which is also used for lifting attachments and implements. The PTO shaft is the part of the equipment located in the tractor.
Swaraj 843 XM tractor has 2730 CC CC displacement in CC. The tires and battery capacity tell the smooth functioning of the tractor. Tractor Swaraj 843 XM has 4 Cylinder number of cylinders. You will get 38.4 PTO HP PTO HP in the tractor Swaraj 843 XM.
This tractor provides a 8 Forward + 2 Reverse Fully Constant gearbox.
