ACE VEER 20 Specifications
ACE VEER 20
2WD 3.30 Lakh - 3.60 LakhSpecifications
| ACE VEER 20 Engine | |
|---|---|
| Engine rated RPM | 540 RPM |
| HP Category | 20 HP |
| Displacement CC in | 863 CC |
| No. of cylinder | 1 Cylinder |
| Max Torque - Nm | 49 Nm |
| Air Cleaner / Filter | oil bath |
| Cooling System | water-cooled |
| Emission standard | Bharat/TREM III A |
| Fuel type | diesel |
| Fuel Pump Type | inline |
| Power KW | 11.2 KW |
| stroke in (mm) | 110 mm |
| Bore in (mm) | 100 mm |
| Fuel Pump Capacity | 19 L Lit |
| Dry Weight kg | 840 Kg |
| Height | 1800 mm |
| Starter Motor | 12 V, 1.6 |
| Accessories | Tools Kit, Front Bumper, Top Link |
| Shifting Type | sliding mesh gearbox |
| Hydraulics | 600 |
| Cylinder Capacity cc | 863 CC |
| ACE VEER 20 Transmission | |
| Transmission type | sliding mesh |
| No. of gears Forward | 6 Forward |
| No. of gears Reverse | 3 Reverse |
| Speed Forward - kmph | 28 Kmph |
| Speed Reverse - kmph | 6 Kmph |
| Brakes type | disc |
| clutch type | dry friction plate |
| Gear Box Type | 6 Forward + 3 Reverse |
| Front Axle | NA |
| Rear Axle | NA |
| Linkage Category | Category I |
| ACE VEER 20 Power Take Off | |
| Max PTO (HP) | 17.2 HP |
| PTO RPM @ engine, rpm | 1616 RPM |
| PTO Type | 17.2 |
| PTO Speed | 540 |
| ACE VEER 20 Steering | |
| Steering Column | ensuring smooth handling |
| Steering type | power |
| ACE VEER 20 Hydraulic | |
| Lifting Capacity Max. | 600 Kg |
| 3 Point Linkage | category I |
| Spool Valve | auxiliary |
| Type | 2WD |
| Pump Type | inline fuel |
| Lower Link | Category II |
| ACE VEER 20 Dimensions & Weight | |
| Ground Clearance | 265 Nm |
| Total Weight | 840 Kg |
| Turning radius With Brake | 2400 Nm |
| Turning radius Without Brake | 2400 mm |
| Overall Length | 2550 mm |
| Overall Width | 1220 mm |
| Wheel Base | 1490 mm |
| Height | 1800 |
| ACE VEER 20 Wheels & Tyres | |
| Tyre Size Front | 5.25 × 14 |
| Tyre Size Rear | 8 × 18 |
| Type Front | NA |
| Type Rear | NA |
| Type | 2WD |
| Wheel Track Front | 950 |
| Wheel Track Rear | 1000 |
| ACE VEER 20 Electrical | |
| Battery Capacity | 12 V, 50 Ah AH |
| Alternator | 12 V, 43 A |
| Battery Type | 12V |
| Horn | NA |
| Indicator & Gauge | NA |
| Electrical System | NA |
| Electrical Overview | NA |
| ACE VEER 20 Others | |
| Blow Rating | NA |
| Tractor Detail | NA |
| Accessories | NA |
| Special Application | NA |
Please read Safety Tips carefully before making any purchase
Know More
ACE VEER 20 Tractor
The agricultural sector plays a vital role in the Indian Economy. But, nowadays agricultural farming depends on advanced machinery, tools, and equipment. You will get ACE VEER 20 tractor specifications here. Every new day, new brand tractors are coming up with advanced features and technology and are boosting the Indian market as well as satisfying the needs of the farmers. ACE VEER 20 tractor is manufactured by one of the most popular brands In India, 22- 23 tractor brands are manufactured across the country with excellent specifications and automotive productions.
If we talk about the tractors, so every tractor has its own specialty in the form of features and the benefits provided in them. ACE is one of the trusted brands in India. These features help the customers to research and compare with the other tractor models. ACE VEER 20 has 20 HP. Some of the specific features that buyer's focussed before purchasing the tractor are utility, budget, comfort and safety, comparison, and consultation with the dealers.
Additionally, the specifications are listed as more 'engine power' and more tractor runs. You will get 0-20 HP Range in ACE VEER 20. The other factor goes with the transmission which includes gears, reverse, and forward speed, the functioning of brakes, and power of the single and dual-clutch system. ACE VEER 20 tractor has 2WD. The hydraulics make the turning easier which is also used for lifting attachments and implements. The PTO shaft is the part of the equipment located in the tractor.
ACE VEER 20 tractor has 863 CC displacement in CC. The tires and battery capacity tell the smooth functioning of the tractor. Tractor ACE VEER 20 has 1 number of cylinders. You will get 6 Forward + 3 Reverse PTO HP in the tractor ACE VEER 20.
This tractor provides a 17.2 gearbox.
So, if you are looking for the tractor price of the tractor go through the official links, websites, and dealers and services like Khetigaadi that provide reliable information to the customers.
