| Adjustment : | Mechanical variator |
|---|---|
| Air cleaner : | Combination of Dry & Wet Type |
| Cleaning Sieve Lower Area : | 1.7 m² |
| Cleaning Sieve Upper Area : | 2.5 m² |
| Cooling system : | Water Cooled |
| Cutter Bar width(mm) : | 14 Feet (4.3 m) |
| Fuel tank capacity : | 365 Ltr |
| Grain tank capacity : | 2.6 m³ |
| Ground Clearance : | 340 mm |
| Height : | 3800 mm |
| Length : | 8370 mm |
| No of Blades : | 57 |
| No of cylinder : | 6 |
| No of steps : | 5 |
| No of straw walker : | 5 |
| Power/Engine HP : | 105 BHP@ 2200 rpm / 102 BHP@2200 rpm |
| Straw Walker Length : | 3770 mm |
| Straw Walker Width : | 234 mm |
| Threshing Drum Diameter : | 606 mm |
| Threshing Drum Width : | 1250 mm |
| Threshing Speed : | 540-1200 rpm |
| Tyre Size Front : | 18.4 / 15X30 |
| Tyre Size Rear : | 9.00X16 |
| Weight(kg) : | 8580 |
| Width : | 4665 mm |
