| Applicable fuel : | Diesel light oil |
|---|---|
| Battery (kg/hm2) : | 12V, 36Ah [50B24L] |
| Cooling system : | Water-cooled |
| Distance between rows ( cm ) : | 30 |
| Engine type : | Water-cooled, 4-cycle, 3-cylinder vertical type diesel engine |
| Front wheel : | No-puncture tire |
| Fuel tank capacity : | 17 |
| Height : | 2030 |
| Hill space ( cm ) : | *12, 14, 16, 18, 21 |
| Length : | 3350 |
| Minimum ground clearance (mm) : | 540 |
| No of cylinder : | 3 |
| Number of leaves : | 2.0 to 4.5 |
| Number of planting rows : | 8 |
| Number of shifting positions : | Main shift: Variable speeds for forward and reverse [sub shift: 2 positions] |
| Number of [Crossfeed distance] (mm/times) seedlings per hil [ Vertical taking quantity ] : | *11/26, 14/20, 18/16 [3 positions] *8 to 18 |
| Operation efficlency ( acre/h ) : | Max. 77 {8.0} |
| Output / revolution speed ( kW {PS} / rpm ) : | 15.4 {21.0} / 3000 |
| Planting depth ( cm ) : | *1.7-5.0 [5 positions] |
| Planting speed ( m/s ) : | 0 to 1.65 |
| Power/Engine HP : | 17 |
| Rear wheel : | Rubber lug wheel |
| Seedling height ( cm ) : | 8 to 25 |
| Seedling type : | Seedling mat |
| Shifting system : | Hydrostatic transmission [HST] |
| Starting system : | Starter motor |
| Total displacement ( L {cc} ) : | 0.898 {898} |
| Weight(kg) : | 746 |
| Width : | 2820 <At the folding : 2220> |
