New Holland
New Holland Excel 6010 4WD and New Holland 6010 4WD
New Holland Excel 6010 4WD
60 HP
9.6 Lakh - 10.1 Lakh
|
New Holland 6010 4WD
60 HP
11.2 Lakh - 12.9 Lakh
|
| Engine | |||||
|---|---|---|---|---|---|
| Engine type | FPT S8000 Series | FPT 8000 | |||
| Engine rated RPM | 2200 RPM | N/A | |||
| HP Category | 60 HP | 60 HP | |||
| No. of cylinder | 3 Cylinder | 3 Cylinder | |||
| Air Cleaner / Filter | Dry Type, Dual Element | Dry Air Cleaner | |||
| Cooling System | Intercooler | N/A | |||
| Fuel type | Diesel | Diesel | |||
| Fuel Pump Type | Rotary | Rotary | |||
| Hydraulics | 2000 / 2500 | 2000 / 2500 | |||
| Transmission | |||||
| Transmission type | Fully Synchromesh With Mechanical Shuttle / Power Shuttle | Full Constant Mesh / Full Synchromesh | |||
| No. of gears Forward | 12 / 20 / 24 Forward | 12 Forward | |||
| No. of gears Reverse | 12 / 20 / 24 Reverse | 12 Reverse | |||
| Speed Forward - kmph | 0.27 - 36.09 Kmph | N/A | |||
| Speed Reverse - kmph | 0.32 - 38.33 Kmph | N/A | |||
| Brakes type | Mechanicallly Actuated Oil Immersed Multi Disc Brake- Standard Hydraulically Actuated Oil Immersed Multi Disc Brake- Optional | Mechanicallly Actuated Oil Immersed Multi Disc Brake- Standard Hydraulically Actuated Oil Immersed Multi Disc Brake- Optional | |||
| clutch type | Double Clutch with Independent Clutch Lever | Double Clutch with Independent Clutch Lever | |||
| Gear Box Type | 12 Forward + 12 Reverse/20 Forward + 20 Reverse/24 Forward + 24 Reverse Fully Synchromesh | 12 Forward + 12 Reverse | |||
| Power Take Off | |||||
| Max PTO (HP) | 51 HP | N/A | |||
| PTO RPM @ engine, rpm | 540 @ 2199 E RPM with 6 Splines Shaft RPM | 540 @ 2199 E RPM with 6 Splines Shaft RPM | |||
| PTO Type | 540 & 540E | N/A | |||
| Steering | |||||
| Steering type | Hydrostatic Steering | Hydrostatic Steering | |||
| Hydraulic | |||||
| Lifting Capacity Max. | 2000 / 2500 Kg | 2000 / 2500 Kg | |||
| Dimensions & Weight | |||||
| Total Weight | 2630 Kg | 2630 Kg | |||
| Wheel Base | 2010 mm | 2010 mm | |||
| Wheels & Tyres | |||||
| Tyre Size Front | 9.50 x 24 ( 0.241 m x 0.610 m ) | 9.5 x 24 | |||
| Tyre Size Rear | 16.9 x 28 ( 0.429 m x 0.711 m ) | 16.9 x 28 | |||
| Electrical | |||||
| Battery Capacity | 100 Ah AH | N/A | |||
| Alternator | 55 | N/A | |||
| Others | |||||
