Force Motors
Force Motors Balwan 400
Force Motors Balwan 400
40 HP
6.4 Lakh - 6.85 Lakh
|
| Engine | |||||
|---|---|---|---|---|---|
| Engine type | 4 Stroke, Inline, Direct Injection | ||||
| Engine rated RPM | 2200 RPM | ||||
| HP Category | 40 HP | ||||
| Displacement CC in | 1947 CC | ||||
| No. of cylinder | 3 Cylinder | ||||
| Max Torque - Nm | 110.4 Nm | ||||
| Air Cleaner / Filter | Dry Type | ||||
| Cooling System | Water Cooled | ||||
| Fuel type | Diesel | ||||
| Hydraulics | 1350 / 1450 | ||||
| Transmission | |||||
| Transmission type | Synchromesh Trans Axle | ||||
| No. of gears Forward | 8 Forward | ||||
| No. of gears Reverse | 4 Reverse | ||||
| Brakes type | Fully Oil Immersed Multiplate Sealed Disc Brakes | ||||
| clutch type | Dry, Dual Clutch Plate | ||||
| Gear Box Type | 8 Forward + 4 Reverse | ||||
| Power Take Off | |||||
| PTO RPM @ engine, rpm | 540 & 1000 RPM | ||||
| Steering | |||||
| Steering type | Mechanical Steering | ||||
| Hydraulic | |||||
| Lifting Capacity Max. | 1350 / 1450 Kg | ||||
| 3 Point Linkage | Category II (Reversible with Adjustable Check Chain) | ||||
| Type | A.D.D.C System with Bosch Control Valve | ||||
| Dimensions & Weight | |||||
| Ground Clearance | 334 Nm | ||||
| Total Weight | 1860 Kg | ||||
| Turning radius With Brake | 3000 Nm | ||||
| Overall Length | 3330 mm | ||||
| Overall Width | 1670 mm | ||||
| Wheel Base | 1890 mm | ||||
| Wheels & Tyres | |||||
| Tyre Size Front | 6.00 x 16 | ||||
| Tyre Size Rear | 13.6 x 28 | ||||
| Electrical | |||||
| Battery Capacity | 12 V 75 Ah AH | ||||
| Alternator | 14 V 23 A | ||||
| Battery Type | Lead Acid | ||||
| Others | |||||
