Escorts Powertrac 439 DS Plus
Escorts Powertrac 439 DS Plus
39 HP
5.5 Lakh - 5.9 Lakh
|
| Engine | |||||
|---|---|---|---|---|---|
| Engine rated RPM | 2200 RPM | ||||
| Displacement CC in | 2146 CC | ||||
| No. of cylinder | 3 Cylinder | ||||
| Transmission | |||||
| No. of gears Forward | 8 Forward | ||||
| No. of gears Reverse | 2 Reverse | ||||
| Speed Forward - kmph | 2.7-30.6 Kmph | ||||
| Speed Reverse - kmph | 3.3-10.2 Kmph | ||||
| Brakes type | Multi Plate Oil Immersed Disc Brake / Multi Plate Dry Disc Brake optional | ||||
| clutch type | Single Clutch / Dual optional | ||||
| Front Axle | Straight/Bend Axle Option | ||||
| Rear Axle | Inboard Reduction | ||||
| Power Take Off | |||||
| PTO RPM @ engine, rpm | 1800 RPM | ||||
| PTO Type | Single 540 | ||||
| Steering | |||||
| Hydraulic | |||||
| Lifting Capacity Max. | 1500 Kg | ||||
| Dimensions & Weight | |||||
| Ground Clearance | 400 Nm | ||||
| Total Weight | 1850 Kg | ||||
| Turning radius With Brake | 3200 Nm | ||||
| Overall Length | 3225 mm | ||||
| Overall Width | 1750 mm | ||||
| Wheel Base | 2010 mm | ||||
| Wheels & Tyres | |||||
| Tyre Size Front | 6.0 x 16 | ||||
| Tyre Size Rear | 12.4X28 / 13.6X28 Option | ||||
| Electrical | |||||
| Others | |||||
