New Holland 5630 Tx Plus Specifications


New Holland 5630 Tx Plus

4WD Get On Road Price



Engine type FPT S8000 Series
Engine rated RPM 2300 RPM
Engine HP 75 HP
Displacement CC in 3908 CC
No. of cylinder 4 Cylinder
Max Torque - Nm NA
Air Cleaner / Filter Dry Type, Dual Element
Cooling System Water Cooled
Emission standard NA
Fuel type Diesel
Fuel Pump Type Rotary FIP
Power KW NA
stroke in (mm) NA
Bore in (mm) NA
Fuel Pump Capacity NA
Fuel Tank Capacity 60 ltrs
Dry Weight kg NA
Height NA
Starter Motor NA
Accessories Tool, Top Link, Canopy, Hook, Bumpher, Drarbar
Shifting Type NA
Hydraulics 2000 Kg With Assist RAM


Transmission type Partial Synchro Mesh
No. of gears Forward 8 / 12 CR / 12 UG
No. of gears Reverse 2 / 3 CR / 3 UG
Speed Forward - kmph 2.14 - 32.07 kmph
Speed Reverse - kmph 3.04 - 16.21 kmph
Brakes type Mechanically Actuated Oil Immersed Multi Disc Brakes
clutch type Double Clutch with Independent Clutch Lever
Gear Box Type NA
Front Axle NA
Rear Axle NA

Power Take Off

Max PTO (HP) 65 PTO HP
PTO RPM @ engine, rpm 540 @ 1967
PTO Type Multi Speed Reverse PTO
PTO Speed NA


Steering Column NA
Steering type Power Steering


Lifting Capacity Max. 2000 Kg With Assist RAM
3 Point Linkage NA
Spool Valve NA
Type NA

Dimensions & Weight

Ground Clearance 405 mm
Total Weight 2770 / 2900 kg
Turning radius With Brake NA
Turning radius Without Brake NA
Overall Length 3800 mm
Overall Width 2000 mm
Wheel Base 2205 mm

Wheels & Tyres

Tyre Size Front 6.50 x 20 / 11.2 x 24 mm
Tyre Size Rear 18.4 x 30 mm
Type Front NA
Type Rear NA


Battery Capacity 100 Ah
Alternator 55 Amp
Battery Type NA


New Holland 5630 Tx Plus Tractor

The agricultural sector plays a vital role in the Indian Economy. But, nowadays agricultural farming depends on advanced machinery, tools, and equipment. You will get New Holland 5630 Tx Plus tractor specifications here. Every new day, new brand tractors are coming up with advanced features and technology and are boosting the Indian market as well as satisfying the needs of the farmers. New Holland 5630 Tx Plus tractor is manufactured by one of the most popular brands In India, 22- 23 tractor brands are manufactured across the country with excellent specifications and automotive productions.

If we talk about the tractors, so every tractor has its own specialty in the form of features and the benefits provided in them. New Holland is one of the trusted brands in India. These features help the customers to research and compare with the other tractor models. New Holland 5630 Tx Plus has 75 HP. Some of the specific features that buyer's focussed before purchasing the tractor are utility, budget, comfort and safety, comparison, and consultation with the dealers.

Additionally, the specifications are listed as more 'engine power' and more tractor runs. You will get 71-80 HP Range in New Holland 5630 Tx Plus. The other factor goes with the transmission which includes gears, reverse, and forward speed, the functioning of brakes, and power of the single and dual-clutch system. New Holland 5630 Tx Plus tractor has 4WD. The hydraulics make the turning easier which is also used for lifting attachments and implements. The PTO shaft is the part of the equipment located in the tractor.

New Holland 5630 Tx Plus tractor has 3908 CC CC displacement in CC. The tires and battery capacity tell the smooth functioning of the tractor. Tractor New Holland 5630 Tx Plus has 4 Cylinder number of cylinders. You will get 65 PTO HP PTO HP in the tractor New Holland 5630 Tx Plus.

This tractor provides a NA gearbox.

So, if you are looking for the purchase of the tractor go through the official links, websites, and dealers and services like Khetigaadi that provide reliable information to the customers.
